제품 사양 |
Risetime(20~80%) |
60 ps(CT100HF), 100 ps(CT100B) |
Amplitude (into 50Ω load) |
300 mV |
Sequential sampling rate |
2 - 250 kHz |
Sampling resolution |
16 bits |
TDR frame rate |
500 fps |
Horizontal scale |
0.003 - 200 ft/div (0.001 - 50 m/div) |
Horizontal range |
0 - 30,000 ft(0 - 9 km)† |
Horizontal resolution |
0.003 in (0.075 mm) |
Vertical scale |
0.5 - 500 mρ/div |
Battery life |
> 6h ‡ |
Battery recharge |
< 3h ‡ |
I/O options |
USB host/client 10/100 Ethernet |
Data storage |
Thousands of traces |
Network integration |
10/100 Mb Ethernet |
Display |
4.3" 480x272 backlit color TFT-LCD |
TDR trace |
Unlimited |
TDR digital filtering |
Smooth, Subtract, Derivatives, FFT, S-paramters, Many others |
