| Model |
Frequency |
Interface |
VSWR Max. |
| JADK1K1 |
DC ~ 40 GHz |
2.92 mm(male) to 2.92 mm(male) |
<1.22 |
| JADK1K0 |
DC ~ 40 GHz |
2.92 mm(male) to 2.92 mm(female) |
<1.22 |
| JADK0K0 |
DC ~ 40 GHz |
2.92 mm(female) to 2.92 mm(female) |
<1.22 |
| JADV1K1 |
DC ~ 40 GHz |
2.4 mm(male) to 2.92 mm(male) |
<1.22 |
| JADV1K0 |
DC ~ 40 GHz |
2.4 mm(male) to 2.92 mm(female) |
<1.22 |
| JADV0K1 |
DC ~ 40 GHz |
2.4 mm(female) to 2.92 mm(male) |
<1.22 |
| JADV0K0 |
DC ~ 40 GHz |
2.4 mm(female) to 2.92 mm(female) |
<1.22 |
| JADV1V1 |
DC ~ 50 GHz |
2.4 mm(male) to 2.4 mm(male) |
<1.25 |
| JADV1V0 |
DC ~ 50 GHz |
2.4 mm(male) to 2.4 mm(female) |
<1.25 |
| JADV0V0 |
DC ~ 50 GHz |
2.4 mm(female) to 2.4 mm(female) |
<1.25 |
| JADSMP1K1 |
DC ~ 40 GHz |
SMP(male) to 2.92 mm(male) |
<1.25 |
| JADSMP1K0 |
DC ~ 40 GHz |
SMP(male) to 2.92 mm(female) |
<1.25 |
| JADSMP0K1 |
DC ~ 40 GHz |
SMP(female) to 2.92 mm(male) |
<1.25 |
| JADSMP0K0 |
DC ~ 40 GHz |
SMP(female) to 2.92 mm(female) |
<1.25 |
